Zte gpon olt products are most popular in Mid East, South America, and Eastern Europe. You can ensure product safety by selecting from certified suppliers, including 600 with ISO9001, 445 with Other, and 116 with ISO14001 certification.
Need Help Now? Get help from our experienced consultants Learn more With the requirements of communication services increasing, the value-added services (VAS) including 3D network games, video conference/phone, Video on Demand (VoD) and IPTV are key means for operators to provide differential services to attract more subscribers, and gain income growth.
The ZXA10 C320 is a small size, full-service optical access convergent platform, provides carrier class QoS and reliable network to meet the requirements for small-scale implementation of FTTx services. Product Features. Unified platform for GPON, EPON and P2P. Small size and compact design, flexible network and fast deployment. 2U frame with 2 service slots, compatible with ZXA10 C300 line cards. Abundant service support capability: IPTV, VoIP, HSI, VPN, mobile backhaul, etc.
Low-cost Way for Full Service Provisioning and Network Convergence Time and clock synchronization function, supports synchronous Ethernet and TDM clock source to meet the networking and service requirements for mobile backhaul. Supports IGMP Router/Snooping/Proxy protocols, SCB and two-level multicast duplication functions, provide reliable multicast control mechanism and abundant IPTV profiles. IPv4 and IPv6 dual stack function, supports IPv6 service processing and forwarding, IPv6 QoS and multicast service bearing. Meets the operator’s requirements for smooth network and service evolvement to IPv6. Efficient Management, End-to-end Comprehensive Service Guarantee Auto Operation and Maintenance System: Provides the industrial first Automatic FTTx network diagnosing and trouble-shooting system. Unified Management Platform: Provides the ZTE NetNumen U31, an integrated Network Management System (NMS), for operators’ network and equipment management. Expert Support Platform: Accessorized the ZXESS EasyserviceTM system to provide end-to-end service estimation, confirmation, detecting, analysis, alarm, diagnosis and optimization.
The SmartAX MA5680T series are developed based on Huawei's third generation unified platform and are the first aggregation OLTs in the world. The MA5680T series integrate the aggregation and switching functions, provide the high-densityxPON, Ethernet P2P, and GE/10GE ports, and provide the TDM and Ethernet private line services with high clock precision to support smooth Internet access service, video service, voice service, and high-reliabilityservice access. This series improve the network reliability, reduce the investment in network construction, and reduce the O&M costs. The MA5680T series include the large-capacity SmartAX MA5680T and the medium-capacity SmartAX MA5683T. The hardware and software of these two models are fullycompatible with each other to reduce the costs of goods preparation for the network.
In these two models, the SmartAX MA5680T provides 16 service slots and the SmartAX MA5683T provides 6 service slots. Large-capacity shared platform The MA5680T series provide the large-capacityshared platform that supports a high-speed switching capacity Developed based on the iMAP hardware platform and the IAS software platform of Huawei, the MA5680T series adopt advanced architecture and design. The switching capacity of the backplane is up to 3.2 Tbit/s. The bidirectional switching capacity of the control board is up to 480 Gbit/s. The GPBD board supports eight GPON ports and the entire subrack supports up to 8K ONTs.
The EPBD board supports eight EPON ports. Based on the 1:64 split ratio, the entire subrack supports up to 8K ONTs. Sharing the development platform with Huawei's broadband access devices, the MA5680T series support the Layer 2 and Layer 3 features of the broadband access devices to provide user-oriented and future-oriented functions. Powerful integrated GPON/EPON access capability 1. EPON access capability The point to multi-point (P2MP) architecture is used to support the passive optical transmission over Ethernet. Symmetrical upstream and downstream rates of 1.25 Gbit/s are supported to provide the high-speed broadband services, meeting the bandwidth requirements of access users.
In the downstream direction, the bandwidth is shared by different users in the encrypted broadcast mode. In the upstream direction, time division multiplex(TDM) is used to share the bandwidth.
The MA5680T series support dynamic bandwidth allocation (DBA) with the granularity of 64 kbit/s. Therefore, the bandwidth of ONT terminal users can be dynamically allocated based on the user requirements. The EPON system uses the passive optical transmission technology, and the optical splitter uses the P2MP mode and supports a split ratio of 1:64. The supported transmission distance is up to 20 km. The ranging technologycan be scheduled ranging, automatic ranging, or initial ranging.
GPON access capability High rate is supported. The downstream rate is up to 2.488 Gbit/s and the upstream rate is up to 1.244 Gbit/s. Long distance is supported. The maximum physical transmission distance of the ONT is 60 km. The physical distance between the farthest ONT and the nearest ONT can be up to 20 km. High split ratio is supported. The 8-port GPON access board supports a split ratio of 1:128, which increases the capacity and saves the optical fiber resources.
High densityis supported. The MA5680T series provide the 8-port or 4-port GPON access board to increase the system capacity. The H-QoS (hierarchical quality of service) function is supported to meet the SLA requirements of various commercial customers. Powerful QoS capability The MA5680T series provide the following powerful QoS solutions to facilitate the management of various services: Supports prioritycontrol (based on the port, MAC address, IP address, TCP port ID, or UDP port ID), priority mapping and modification based on the ToS field and 802.1p, and DSCP differentiated services.
Supports bandwidth control (based on the port, MAC address, IP address, TCP port ID, or UDP port ID) with a control granularity of 64 kbit/s. Supports three queue scheduling modes: priority queue (PQ), weighted round robin (WRR), and PQ+WRR. Supports HQoS, which assures the multi-service bandwidth for multiple users: The first level assures the user bandwidth, and the second level assures the bandwidth for each service of each user. This ensures that the assured bandwidth is allocated absolutely and the burst bandwidth is allocated fairly. Comprehensive security assurance measures The MA5680T series meet the securityrequirements of the telecommunication services, fully use the security protocols, and fully ensure the security of the system and the user. System security measure Protection against the DoS (denial of service) attack MAC (media access control) address filtering Anti-ICMP/IP packet attack Source address routing filtering Blacklist 2. User security measure DHCP (Dynamic Host Configuration Protocol) Option 82 to enhance the DHCP security Binding between MAC/IP addresses and ports Anti-MAC spoofing and anti-IP spoofing Authentication based on the serial number (SN) and password of the ONU/ONT Triple churning encryption Encrypted broadcast transmission in the GPON downstream direction for different users, such as AES (advanced encryption standard) 128-bit encryption GPON type B OLT dual homing Smart link and monitor link for the network with dual upstream channels.
Carrier-class reliability design The system reliability of the MA5680T series is taken into consideration in the system, hardware, and software designs to ensure that the device runs in the normal state. The MA5680T series: Provides the lightning-proof and anti-interference functions.
Supports fault pre-warning on the exhaustive (consumed) units and parts, such as the fan, power supply, and battery. The 1+1 (type B) protection for the PON port and the 50 ms level service protection switchover for the backbone optical fiber are supported.
Supports in-service upgrade. Supports high temperature detection to ensure the system safety. The functions of querying the board temperature, setting the temperature threshold, and high temperature shutdown are supported. Adopts 1+1 redundancy backup for the control board and the upstream interface board. Supports hot swappable for all service boards and the control boards.
Zte Gpon
Provides soft-start circuit, protective circuit, current-limit protection, and short circuit protection for the input power of the boards in the subrack to protect the boards against lightning strikes and surges. Supports GPON type B/type C OLT dual homing. Supports smart link and monitor link for the network with dual upstream channels. Huawei MA5683T is a aggregation Optical Line Terminal (OLT), it supports up to 6 service slots and can support maximum 12,000 subscribers (GPON). A typical MA5683T configuration includes one MA5683T Chassis, two Main Control Board SCUN/SCUK, two Power Board PRTE, one uplink board GICF (2 GE Optical with SFP Module), one 8 Port GPON board GPBD (with C+ SFP Module).
This series features the industry’s first aggregation Optical Line Terminal (OLT), integrating ultra-high aggregation and switching capabilities, supporting 3.2T backplane capacity, 960G switching capacity, 512K MAC addresses, and a maximum of 44-channel 10 GE access or 768 GE ports. High reliability Provides highly reliable networking capabilities and ensures dual-OLT hot backup, remote disaster tolerance, and service upgrades without interruption. Provides comprehensive Quality of Service (QoS) functions and supports traffic classification management, priority control, and bandwidth control. The Hierarchical-Quality of Service (H-QoS) function meets various Service Level Agreement (SLA) requirements of commercial customers.
Provides an End-to-End (E2E) highly reliable design, enabling Bidirectional Forwarding Detection (BFD), Smart Link, Link Aggregation Control Protocol (LACP) redundancy protection and GPON type B/type C line protection in the upstream direction. Multi-scenario access Supports access of multiple E1 private line services, and Native Time-Division Multiplexing (TDM) or Circuit Emulation Services over Packet (CESoP)/ Structure-Agnostic TDM over Packet (SAToP) function. Supports the Emulated Local Area Network (ELAN) function and Virtual Local Area Network (VLAN)-based internal traffic exchange, satisfying enterprise and community network application requirements. Supports non-convergence access of Internet Protocol television (IPTV) users. One subrack supports 8,000 multicast users and 4,000 multicast channels.
The MA5608T Mini OLT is designed to address Fiber to the premise (FTTP) or deep fiber deployment scenarios where a large OLT chassis may not be the best fit for a variety of reasons. 1.12.1 vanilla wow client. Huawei’s mini OLT MA5608T is designed to be the perfect complement to the other MA5600 series larger OLTs and offers the same carrier grade features and performance.
MA5608T’s compact and front access design make it an ideal solution for deployments in locations such as space-constrained huts, outdoor cabinets or building basements. It has AC and DC powering options, extended temperature range, and offers easy installation. Designed to support ever-increasing bandwidth demand, MA5608T has 200 Gbps backplane. The combination of the high-capacity and line interf The MA5608T shares the same product architecture with the MA5600 series OLTs to allow seamless network growth.
Zte Gpon Ont
It features: 1. Shared services cards including GPON, XG-PON1 and VDSL2+POTS Combo. Any card, any slot in any combination. Dual switching and control cards for redundancy and loadsharing with GE and 10GE uplinks. Same software features and functions as other MA5600 series OLTs and interoperability with a large suite of ONTs, DSL CPEs, and Softswitches for voice service.
